K3D: Getting Started with ArgoCD

Daniel Pepuho

Cover Image

K3D: Getting Started with ArgoCD

Intro

ArgoCD is a GitOps tool with a straightforward but powerful objective: to declaratively deploy applications to Kubernetes by managing application resources directly from version control systems, such as Git repositories. Every commit to the repository represents a change, which ArgoCD can apply to the Kubernetes cluster either manually or automatically. This approach ensures that deployment processes are fully controlled through version-controlled files, fostering an explicit and auditable release process.

For example, releasing a new application version involves updating the image tag in the resource files and committing the changes to the repository. ArgoCD syncs with the repository and seamlessly deploys the new version to the cluster.

Since ArgoCD itself operates on Kubernetes, it is straightforward to set up and integrates seamlessly with lightweight Kubernetes distributions like K3s. In this tutorial, we will demonstrate how to configure a local Kubernetes cluster using K3D and deploy applications with ArgoCD, utilizing the argocd-example-apps repository as a practical example.

Prerequisites

Before we begin, ensure you have the following installed:

- Docker

- Kubectl

- K3D

- ArgoCD CLI

Step 1: Set Up a K3D Cluster

Create a new Kubernetes cluster using K3D:

Terminal window
$ k3d cluster create argocluster --agents 2


INFO[0000] Prep: Network
INFO[0000] Created network 'k3d-argocluster'
INFO[0000] Created image volume k3d-argocluster-images
INFO[0000] Starting new tools node...
INFO[0000] Starting node 'k3d-argocluster-tools'
INFO[0001] Creating node 'k3d-argocluster-server-0'
INFO[0001] Creating node 'k3d-argocluster-agent-0'
INFO[0001] Creating node 'k3d-argocluster-agent-1'
INFO[0001] Creating LoadBalancer 'k3d-argocluster-serverlb'
INFO[0001] Using the k3d-tools node to gather environment information
INFO[0001] HostIP: using network gateway 172.18.0.1 address
INFO[0001] Starting cluster 'argocluster'
INFO[0001] Starting servers...
INFO[0002] Starting node 'k3d-argocluster-server-0'
INFO[0009] Starting agents...
INFO[0009] Starting node 'k3d-argocluster-agent-0'
INFO[0009] Starting node 'k3d-argocluster-agent-1'
INFO[0017] Starting helpers...
INFO[0017] Starting node 'k3d-argocluster-serverlb'
INFO[0024] Injecting records for hostAliases (incl. host.k3d.internal) and for 4 network members into CoreDNS configmap...
INFO[0026] Cluster 'argocluster' created successfully!
INFO[0026] You can now use it like this:
kubectl cluster-info

Verify that your cluster is running:

Terminal window
$ kubectl get nodes


NAME                       STATUS   ROLES                  AGE   VERSION
k3d-argocluster-agent-0    Ready    <none>                 63s   v1.30.4+k3s1
k3d-argocluster-agent-1    Ready    <none>                 62s   v1.30.4+k3s1
k3d-argocluster-server-0   Ready    control-plane,master   68s   v1.30.4+k3s1

Step 2: Install ArgoCD

Install ArgoCD in your K3D cluster:

Terminal window
$ kubectl create namespace argocd


$ kubectl apply -n argocd -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml


customresourcedefinition.apiextensions.k8s.io/applications.argoproj.io created
customresourcedefinition.apiextensions.k8s.io/applicationsets.argoproj.io created
customresourcedefinition.apiextensions.k8s.io/appprojects.argoproj.io created
serviceaccount/argocd-application-controller created
serviceaccount/argocd-applicationset-controller created
serviceaccount/argocd-dex-server created
serviceaccount/argocd-notifications-controller created
serviceaccount/argocd-redis created
serviceaccount/argocd-repo-server created
serviceaccount/argocd-server created
role.rbac.authorization.k8s.io/argocd-application-controller created
role.rbac.authorization.k8s.io/argocd-applicationset-controller created
role.rbac.authorization.k8s.io/argocd-dex-server created
role.rbac.authorization.k8s.io/argocd-notifications-controller created
role.rbac.authorization.k8s.io/argocd-redis created
role.rbac.authorization.k8s.io/argocd-server created
...

Check the status of ArgoCD pods:

Terminal window
$ kubectl get pods -n argocd


NAME                                                READY   STATUS    RESTARTS   AGE
argocd-application-controller-0                     1/1     Running   0          29m
argocd-applicationset-controller-684cd5f5cc-78cc8   1/1     Running   0          29m
argocd-dex-server-77c55fb54f-bw956                  1/1     Running   0          29m
argocd-notifications-controller-69cd888b56-g7z4r    1/1     Running   0          29m
argocd-redis-55c76cb574-72mdh                       1/1     Running   0          29m
argocd-repo-server-584d45d88f-2mdlc                 1/1     Running   0          29m
argocd-server-8667f8577-prx6s                       1/1     Running   0          29m

Expose the ArgoCD API server locally, then try to accessing the dashboard:

Terminal window
$ kubectl port-forward svc/argocd-server -n argocd 8080:443

ArgoCD

Step 3: Configure ArgoCD

Log in to ArgoCD

Retrieve the initial admin password:

Terminal window
kubectl get secret argocd-initial-admin-secret -n argocd -o jsonpath="{.data.password}" | base64 -d

Log in using the admin username and the password above.

Log in into ArgoCD Dashboard

Connect a Git Repository

Just clone the argocd-example-apps repository:

Terminal window
git clone https://github.com/argoproj/argocd-example-apps.git

Specify the ArgoCD server address in your CLI configuration:

Terminal window
$ argocd login localhost:8080


WARNING: server certificate had error: tls: failed to verify certificate: x509: certificate signed by unknown authorit
y. Proceed insecurely (y/n)? y
Username: admin
Password:
'admin:login' logged in successfully
Context 'localhost:8080' updated

Create a new ArgoCD application using the repository:

Terminal window
$ $ argocd app create example-app \
  --repo https://github.com/argoproj/argocd-example-apps.git \
  --path ./guestbook \
  --dest-server https://kubernetes.default.svc \
  --dest-namespace default


  application 'example-app' created

Sync the application:

Terminal window
$ argocd app sync example-app


TIMESTAMP                  GROUP        KIND   NAMESPACE                  NAME    STATUS    HEALTH        HOOK  MESSAG
E
2025-01-10T11:31:11+07:00            Service     default          guestbook-ui  OutOfSync  Missing
2025-01-10T11:31:11+07:00   apps  Deployment     default          guestbook-ui  OutOfSync  Missing
2025-01-10T11:31:11+07:00            Service     default          guestbook-ui    Synced  Healthy
2025-01-10T11:31:11+07:00            Service     default          guestbook-ui    Synced   Healthy              service/guestbook-ui created
2025-01-10T11:31:11+07:00   apps  Deployment     default          guestbook-ui  OutOfSync  Missing              deployment.apps/guestbook-ui created
2025-01-10T11:31:11+07:00   apps  Deployment     default          guestbook-ui    Synced  Progressing              deployment.apps/guestbook-ui created
...

Step 4: Verify the Deployment

Check that the application is deployed successfully:

Terminal window
$ kubectl get pods


NAME                            READY   STATUS    RESTARTS   AGE
guestbook-ui-649789b49c-zwjt8   1/1     Running   0          5m36s

Access the deployed application by exposing it via a NodePort or LoadBalancer:

Terminal window
$ kubectl port-forward svc/guestbook-ui 8081:80


Forwarding from 127.0.0.1:8081 -> 80
Forwarding from [::1]:8081 -> 80

Guestbook UI

Dashboard App List

Dashboard App

Conclusion

In this tutorial, you’ve set up a local Kubernetes cluster using K3D and deployed applications with ArgoCD. This setup provides a simple and powerful way to practice GitOps workflows locally. By leveraging tools like ArgoCD, you can ensure your deployments are consistent, auditable, and declarative. Happy GitOps-ing!

References

- GitOps on a Laptop with K3D and ArgoCD. https://www.sokube.io/en/blog/gitops-on-a-laptop-with-k3d-and-argocd-en.

- Take Argo CD for a spin with K3s and k3d. https://www.bekk.christmas/post/2020/13/take-argo-cd-for-a-spin-with-k3s-and-k3d.

- Application Deploy to Kubernetes with Argo CD and K3d. https://yashguptaa.medium.com/application-deploy-to-kubernetes-with-argo-cd-and-k3d-8e29cf4f83ee
